PowerVision PowerRay Explorer Marine ROV (Standard Version)

Description

Embark on a journey of underwater discovery with the PowerRay Marine ROV. Whether you’re a filmmaker, marine researcher, angler, or simply an amateur under Sea Explorer, the PowerRay Marine ROV will amaze you with its high quality imagery, nimble maneuverability and diverse functionality. Available in two equipment levels Explorer for those wanting to get started in underwater exploration and Wizard for more advanced users who want that bit extra in ROV functionality.

Features of the PowerRay Marine ROV

Camera: The PowerRay features a 1/2.3 inch CMOS  sensor to deliver 4K UHD video recording resolution as standard and live streaming video at 1080p HD as standard. Still image capture is set at 12 mega pixel by default. Video and still images specifications can be adjusted to lower resolutions if required. Adjustments can also be made to ISO and Burst Shooting features. Built in video stabilization adjusts and holds shooting angles for filming. (-30° to 10°) allowing smoother video shoots and allowing you to capture content like a pro!

Long Battery Life: The PowerRay Marine ROV comes with a 14.8v 6400mAh LiPo battery which can deliver up to 4 hours of sailing time in still water or under light use. Recharging takes 2.5 hours or less.

Bright Lights: The PowerRay Marine ROV features two powerful 3 watt 450 Lumen dimmable LED lamps which are set at 6500K to replicate natural sunlight. This assists by maintaining minimal disturbance to marine life and improving underwater vision.

Fish Finding: Included in the Wizard package are some fantastic features to help anglers improve their chances of fishing success. The PowerSeeker Fish Finder can detect fish up to 230ft below the surface. Its sonar system can detect depth, underwater topography, water temperature data, and fishing hot spots. It can also send alerts to users through the Vision+ app when fish are detected. The bottom of the PowerSeeker is equipped with 6 blue fish luring lights.

Bait Dropping: The PowerRay Marine ROV features an electromagnetic bait dropping device for precision bait dropping right where the fish are – taking your fishing experience to the next level!

Deep Diving: The PowerRay Marine ROV is 100% waterproof and can deep dive to depths of 98 feet – satisfying the needs of divers, fish-seekers, and underwater monitoring. In Depth Hovering mode, PowerRay can hover at a fixed depth within a +- 4 inch accuracy. You’ll never get lost when following your target with this feature.

Communication Cable: The PowerRay features a durable 0.16” diameter communication cable with a working strength of up to 66lbs. The Explorer comes with a 164ft cable and the Wizard comes with a 230ft cable.

Fast: PowerRay’s cutting edge design features two horizontal thrusters and one vertical thruster, allowing PowerRay to swim freely in still water up to 4knots

Storage: The PowerRay Marine ROV features fixed SD storage and is non expandable. The Explorer version comes with 32GB of storage space and the Wizard 64GB of storage space. Access to files on storage is via WiFi.

VR Goggles: Zeiss VR One Goggles are included in the Wizard package. PowerRay’s VR Goggles provide users an immersive First Person View (FPV) experience. Allowing you to interact with the underwater world on many levels.

Vision+App: The Vision+ App is the official app for the PowerRay. It is not only a powerful data terminal but also a virtual controller for PowerRay. The app can acquire detailed information from underwater sonar and navigation. It can present fish distribution. Control the 4K camera parameters with real-time 1080P underwater streaming. Vision+ supports iOS and Android systems and can be downloaded in all major app stores.

Some of the applications of the PowerRay Marine ROV:

Pre-Dive Preparation: Before getting into the water, PowerRay can explore the path and confirm the safety of the dive site. In addition, PowerRay can monitor ocean depths and water temperatures, making sure you are well aware of current diving conditions at your favorite dive sites.

Underwater Engineering: PowerRay can be a great tool for underwater operations. It can be applied to regular inspections of boats, underwater piers, search and rescue missions, scientific research, aquaculture just to name a few.

Aquaculture: The PowerRay is capable of checking fish quantities, density, size of fish, and observe their health at close range with PowerRay.

Underwater Photography and Videography: PowerRay’s integrated 4K UHD camera allows filmmakers to shoot underwater content for movies, research, and creative underwater photography. Take control of PowerRay and explore the underwater world!

 Angling: PowerRay is equipped with an intelligent fish finding sonar to monitor fish, water temperature, water depths and underwater terrain in real time through the mobile app. In addition to that, PowerRay can mount fishing lines and deliver hooked bait to target fishing locations.

PowerRay Specifications

Dimensions	465 x 270 x 126mm (18.3”x 10.6” x 4.9”)
Weight	~3.8kg / 8.37lb (In air)
Operating Temperature	32°F~104°F (0°~40°C)
Depth Capacity	30 m (98.42ft)
Max Cruise Speed	3Kn (1.5m/s) (4.9ft/s) (Still water)
Max Sailing Time	4h (still water, light use) 1.5h (still water, L speed mode cruise) 0.5h (still water, H speed mode racing)
Charging Time	<2.5h
Thruster Configuration	3 thrusters (2 horizontal, 1 vertical)
Flow Resistance	4.5miles/hr(2metres/sec)
Battery	94.72Wh(14.8 6400mAh) LiPo
Battery Cycle Time	>100

Camera

Lens	FOV 95° (In air) F2.8
Sensor	1/2.3 inch CMOS, Effective pixels: 12M
Image Size	12M: 4000*3000 4:3(default) 8M: 3840*2160 16:9 5M: 2560*1920 4:3
Video Resolution	4K： 3840×2160 25fps (default) 1440P：2560×1440 50fps FHD：1920×1080 30/60fps Auto /100/200/400/800/1600
ISO	Auto / 100 / 200 / 400 / 800 / 1600
Burst Shooting	1/3/5 frames
Storage	32G/64G

Lights

Power	3Wx2
Brightness	450 lumens (with dimming control)
Color Temperature	6500K

Live View

Live View Quality	720P 25fps/1080P 30fps
Max Transmission Distance	≥10m (32.80ft)
Operating Frequency	2.4~2.483GHz
EIRP	≤20dbm
Latency	≤300ms

Base Station

Operating Frequency	2.4~2.483GHz
EIRP	≤20dbm
Battery	3000mAh LiPo 1S
Operating Time	≥3h
Charging Time	≤2.5h

Charger

Input	AC100-240V 50/60Hz 1.6A
Output1	16.8V/4.5A (M16 waterproof connector)
Output2	5.0V/2.0A (M12 waterproof connector)
Output3	5.0V/2.0A (Micro USB)
Output4	5.0V/0.2A (USB)

Remote Controller

Operating Frequency	2.4~2.483GHz
EIRP	≤20dbm
Max Transmission Distance	10m(32.80ft)
Battery	3000mAh LiPo 1S
Operating Time	≥20h
Charging Time	≤3.5h
Operating Temperature	32°F~104°F (0~40℃)
Supported Mobile Device	length: 41~175mm

Fishfinder

Dimensions	Round Shape D:68mm
Weight	100g (3.52oz)
Operating Frequency	125KHz
Track Angle	30°
Track Depth	0.6~40m (1.97~131ft)
Operating Temperature	32°F~104°F (0~40℃)
Wireless	Wi-Fi 2.4~2.483GHz
EIRP	≤20dbm
Wi-Fi range	90m (295ft)
Resolution	0.1m
Operating Time	≥2h
Charging Time	≤3h

Communication Cable

Diameter	4.2mm (0.16”)
Length	50m(164ft) / 70m (230ft)
Working Strength	30kg (66.13lb)

Bait Drop

Weight	8g (0.28oz)
Supported Weight	≤120g (4.23oz) (in the water)

VR Goggle

FOV	100°
IPD	53~77mm (2.08”~3.03”)
Supported Mobile Device	4.7’~5.5′
Size	Wear Glass

APP

iOS	iOS 8.0 or later
Android	Android 4.2 or later
